THzNanoVision is an intended spin-off project at the Department of Terahertz Devices and Systems, at the Department of Electrical Engineering and Information Technology, Technical University of Darmstadt. In this project, the Hessian Distr@l program supports the further development and validation of GaN-based terahertz sources. THzNanoVision is led by Dr.-Ing. Ahid S. Hajo.

THzNanoVision develops compact, patented sources for the generation and use of Terahertz (THz) waves in order to create the basis for a cross-sectional technology in the field of data transmission in the long term. THzNanoVision's core innovation is its patented semiconductor technologies that enable the development of biocompatible, low-cost, high-performance, as well as easy-to-install THz sources that are nearly impossible to achieve with current technologies. Our technology, based on semiconductor devices, will in the long term enable wireless communication with the highest bit-rate data transmission over short distances (so-called last mile). The aim is to apply our technology in places where broadband expansion with fiber optic networks is difficult and should also enable the basis for further applications in the area of 6G data transmission and subsequent generations in the future.

THzNanoVision's novel, patented THz source can be generally applied in the fields of telecommunications, non-destructive material testing, and drug or food inspection. The application fields can be extended to biomedical engineering as well as security engineering. The unique value of our THz technology lies in its differentiation from hazardous alternatives such as X-ray and UV technology, as it is biocompatible and safe for human health. Our sustainably oriented sources use gallium nitride (GaN) material, replacing problematic currently used materials on the market, such as the rare indium (In) and the toxic arsenide (As).

In a first application area for non-destructive imaging, we build THz generators in the frequency range mentioned above using our patented field plate and side contact technology. The application of our technology here offers imaging inspection of defects in the millimeter and submillimeter range and products, components and raw materials can be screened non-destructively. Our highly innovative THz source enables fast, non-contact and non-destructive material inspection and can check 100% of the quality of products in production lines. For this purpose, THzNanoVision already has several letters of intent from companies for future cooperation or demand for our diodes. Further companies are planning to integrate our sources in their non-destructive material testing or radar systems in the mid-term. These cooperations would enable us to significantly expand our application and sales channels also in the direction of telecommunications and at the same time provide for an additional, very high scalability of our business model.
